Automotive Charging System Teaching Board

1. Khoom Taw Qhia

CovAutomotive Charging System Teaching Boardyog tsim los ntawm lub tsheb them nyiaj tiag tiag, muab qhov ua tiav thiab nkag siab zoo ntawm cov qauv thiab cov qauv kev ua haujlwm. Cov kws tshaj lij noautomotive hluav taws xob kev cob qhia khoom sivqhia meej txog cov txheej txheem thiab kev ua haujlwm ntawm lub tsheb them nyiaj, ua rau nws zoo tagnrho rau cov tsev kawm ntawv ua haujlwm, tsev kawm qib siab, thiab cov chaw cob qhia tsheb.

Cov cuab yeej txhawb nqa ob qho tib si theoretical qhia thiab txhais tes- ntawm kev xyaum rau kev pib tsheb pib thiab kev them nqi kho mob. Los ntawm kev sib xyaw ua ke ntawm cov khoom siv tiag tiag thiab cov duab kos duab, cov tub ntxhais kawm tuaj yeem cuam tshuam ncaj qha cov qauv txheej txheem nrog hluav taws xob logic, txhim kho lawv txoj kev nkag siab ntawmautomotive charging system kev cob qhia.

2. Khoom ua haujlwm

2.1 Kev Ua Haujlwm Kev Ua Haujlwm Zoo

Lub rooj tsavxwm integrates ib tug tag nrho functional charging system. Thaum lub tshuab hluav taws xob qhib, lub cev muaj zog tsav lub alternator ua haujlwm. Lub teeb qhia kev them nqi hluav taws xob kaw, thiab lub roj teeb lub davhlau ya nyob twg voltage nce, qhia meej meej txog cov txheej txheem ua haujlwm ntawm lub tsheb them nyiaj.

Cov tub ntxhais kawm tuaj yeem saib xyuas kev them nyiaj tam sim no thiab lub roj teeb hluav taws xob los ntawm kev tsim -hauv ammeter thiab voltmeter, paub tseebautomotive hluav taws xob kuaj kev cob qhia.

2.2 Visual Circuit Analysis

Lub vaj huam sib luag yog ua los ntawm qib siab -qib aluminium- yas board, tiv taus kev cuam tshuam, kev sib kis, hluav taws kub, thiab noo noo. Qhov saum npoo yog kho tshwj xeeb thiab luam tawm nrog cov duab uas tsis yog -fading xim Circuit Court.

Cov tub ntxhais kawm tuaj yeem sib piv cov khoom siv lub cev nrog daim duab kos duab, pab lawv nkag siab txog cov ntsiab cai ntawm kev ua haujlwm.automotive alternator system kev cob qhia pawg thawj coj saib.

2.3 Alternator Structure Demonstration

Disassembled alternator Cheebtsam yog ntsia ncaj qha rau ntawm lub vaj huam sib luag, tso cai rau cov tub ntxhais kawm pom qhov pom ntawm cov qauv sab hauv ntawm lub alternator sib dhos. Qhov no txhim kho cov neeg kho tshuab kev paub thiab kev nkag siab ntawm cov qauv hauv kev qhia tsheb them nqi tsheb.

2.4 Kev Ntsuas & Kev Ntsuas Ntsuas

Lub vaj huam sib luag tau nruab nrog cov cuab yeej tshawb nrhiav, ua kom muaj kev ntsuas ncaj qha ntawm cov teeb liab hluav taws xob xws li tsis kam, voltage, tam sim no, thiab zaus.

Qhov kev tsim no txhawb nqa davautomotive hluav taws xob system teeb meem kev cob qhia, suav nrog kev ua yuam kev simulation thiab tshem tawm kev xyaum.

3. Kev qhia tshwj xeeb

Zuag qhia tag nrho Dimensions: 1200 × 600 × 1700 mm (L × W × H)

Ua haujlwm voltage: DC 12V

Ua haujlwm kub: -40℃rau +50 degree

Asynchronous Tsav

Lub hwj chim: AC 220V

Lub Zog: 2.2KW

Ceev: 1420 r / min

Hlau Yeeb Nkab Ncej: 60 × 40 × 3mm

Txee: 1.5mm txias-khoov hlau stamping

Mov Casters: 100 × 60mm

Qhov kev teeb tsa no ua kom muaj kev ua haujlwm ruaj khov rau lub sijhawm ntev -automotive lab kev cob qhia cov cuab yeejkev ua haujlwm.

Vim li cas thiaj xaiv Peb Lub Tsheb Them Nqi Them Nqi Qhia?

Kev them nyiaj yug tiag tiag

Fault simulation thiab kev cob qhia kuaj mob

Integrated professional toolkit suav nrog

High -cov cuab yeej ntsuas qhov tseeb

Ua kom tiav cov yeeb yaj kiab qhia thiab cov ntaub ntawv kawm

Durable industrial- qib qauv

Tsim tshwj xeeb rau kev kawm ua haujlwm thiab kev kawm txuj ci

Peb qhov kev daws teeb meem tsis yog lub rooj tsav xwm nkaus xwb - nws yog ib qho kev qhia davautomotive charging system vocational training solutionrau niaj hnub automotive Laboratories.
